S5720-28X-LI-24S-AC 10G Network Switch 24 Ports 1000Mbps Fast Data Transfer

Ask Lasest Price
Brand Name :	OEM
Model Number :	S5720-28X-LI-24S-AC
Supply Ability :	10000 Set/Sets per Month
Price :	$500.00/sets >=2 sets

Add to Cart

Product Details
Company Profile

S5720-28X-LI-24S-AC 10G Network Switch 24 Ports 1000Mbps Fast Data Transfer

Experience Lightning-Fast Data Transfer with S5720-28X-LI-24S-AC 10G Network Switch

Products Description

S5720-LI Series

The S5720-LI series are energy-saving gigabit Ethernet switches that provide flexible GE access ports and 10 GE uplink ports. Building on high-performance hardware, store-and-forward mode, and Versatile Routing Platform (VRP), the S5720-LI series support intelligent Stack (iStack), flexible Ethernet networking, and diversified security control. They provide customers with green, easy-to-manage, easy-to-expand, and cost-effective gigabit to the desktop solutions.

S5720-28X-LI-24S-AC 10G Network Switch 24 Ports 1000Mbps Fast Data Transfer

Model	S5720-28X-LI-AC(DC) S5720-28X-PWR-LI-AC S5720-28X-LI-24S-AC(DC) S5720-28X-PWR-LI-ACF	S5720-52P-LI-AC S5720-52P-PWR-LI-AC	S5720-52X-LI-AC(DC) S5720-52X-PWR-LI-AC S5720-52X-LI-48S-AC S5720-52X-PWR-LI-ACF
Switching Capacity	336 Gbit/s	336 Gbit/s	336 Gbit/s
Forwarding Performance	108 Mpps	87 Mpps/144 Mpps Note: The specifications, which are to the right of the slash (/), can be achieved by loading the GE to 10G electronic RTU license.	144 Mpps
Fixed Ports	S5720-28X-LI-24S-AC(DC): 24 x Gig SFP ports, 8 of which are dual-purpose 10/100/1,000 Base-T or SFP ports, 4 x 10 Gig SFP+ ports Others: 24 x Ethernet 10/100/1,000 Base-T ports, 4 x 10 Gig SFP+ ports	48 x Ethernet 10/100/1,000 Base-T ports, 4 x Gig SFP ports	S5720-52X-LI-48S-AC: 48 x Gig SFP, 2 of which are dual-purpose 10/100/1,000 Base-T or SFP, 4 x 10 Gig SFP+ Others: 48 x Ethernet 10/100/1,000 Base-T ports, 4 x 10 Gig SFP+ ports
MAC Address Table	16K MAC address entries MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses
VLAN	4,094 VLANs Guest VLAN and voice VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports VLAN mapping Super VLANBasic QinQ and selective QinQ
IP Routing	Static routing, RIP, RIPng, OSPF, and OSPFv3
Interoperability	VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP)

More Products

NETWOK ROUTER

NETWORK SWITCH

FIREWALL

MODLES

WIERLESS AC

WIERLESS AP

Customer Reviews

Company Profile

Certifications

Product packaging

FAQ

Q1: Can I get some samples?
A: Yes, sample order is available for quality check and market test. But you have to pay the sample cost and express cost.

Q2: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.

Q3: What's the lead time.
A: According to the order quantity, small order usually need 3-5 days, big order need negotiation.

Q4: What's your warranty terms?
A: We supply 12 months warranty time.

Q5: What's your payment terms?
A: We receive Escrow, T/T, West Union, Cash and etc
